S.A.M. 4

Description

  • Driving licence class C1E
  • Product presentations (fixed installation of your exhibits possible)
  • PR (pedestrian precincts, supermarkets)
  • Mobile trade fair stands
  • Specialized trade presentations with frequent changes of location
  • Combined events with presenter interludes (open stage)

Floor plan

Floor plan

Floorspace

Available space

Total floorspace 27.40 m² • Presentation space 19.80 m² • Floorspace for permanently installed display items 10.40 m², load bearing capacity up to 1.25 t

Glazed area / stage area 9.40 m² • Kitchen area 4.80 m² • Storeroom 2.80 m²

Dimensions

Total length when set up with truck 12.54 m

Length in roadworthy and set up condition without truck 9.11 m

Width in roadworthy condition 2.35 m • Width when set up 4.46 m

Height in roadworthy condition 3.30 m • Height when set up 3.30 mInterior



Interior

Entrance area

Open entrance via stage platform 1 • Glass swing door • Width approx. 1.30 m when the glazed area is closed

Kitchen

Hanging and standing cupboards • Stainless steel sink • 160-litre refrigerator • 20-litre fresh water tank • 20-litre waste water tank

Performance

Refrigeration

Refrigeration power 12,000 W

Heating

Heating power, engine-independent heating 5,000 W

Electricity supply

Generator, soundproofed • Nominal rating: 11,900 W • Continuous rating: 10,700 W or external 400 V/16 A power connection

Advertising

Advertising areas

The FRP surface of the promotional trailer can be entirely film-wrapped.

This service is supplied by a GetGoing specialist company.

Extras

Extras

Additional features

Variable glass elements mean the entire stage area can be opened • Hydraulic vehicle • Glazed area / stage can be hydraulically set up • Air suspension
